4K 4×1 Multi-Format Wireless Collaboration Switcher with Wired and Wireless Connectivity

SKU: EVSW4K41 Categories: , , ,

Description

  • 4×1 collaboration switcher with wired and wireless connectivity
  • Perfect solution for conference room and presentation applications
  • Supports Miracast/Airplay for wireless connection
  • Supports HDMI 2.0b, [email protected], 4:4:4, HDR and HDCP 2.2 with HDR
  • HDR10 and Dolby Vision compatible
  • Wireless BYOD (Bring Your Own Device) capability via AirPlay and Miracast
  • Soft Codex capabilities for integration with 3rd party video conferencing software
  • Provides up to 60w charging, USB data (USB 3.0/2.0) and 4K video transmission on USB-C port
  • Audio de-embedding built in to break out audio to an amplifier or audio distribution system
  • Two type-B USB ports for host connection; two type-A USB ports for USB devices such as webcams, mouse, keyboard, etc
  • Auto-switching mode
  • Smart EDID management
  • Front panel buttons trigger both CEC and RS232 commands for display control
  • Dimensions: 9.37” x 1” x 5.3” (238mm x 24.5mm x 135mm)

Package Contents:
EVSW4K41 Collaboration Switcher
(1) 5-pin Phoenix Connector
(1) External Antenna
(1) RS-232 Cable (3-pin to DB9)
(2) Mounting Ears and (4) Mounting Screws
24V DC 5A Power Adapter
Product Manual



Additional information

Brands

Evolution

EVSW4K41 Product Manual

Download

EVSW4K41 SALES SHEET

Download
