Evolution HDMI® over Single Cat5e/Cat6 Cable Extender with ARC

SKU: EVEX2007 Categories: ,

This product has been discontinued.

Description

  • Transmits HDMI video- audio and control signals over a single Cat5e/6 cable up to 164ft/50m at 1080p 60 Hz
  • Supports Bi-directional IR control- Dual-Band IR (20-60KHz)- EDID call back- CEC pass through and ARC (audio return channel)
  • ARC pass through feature supports stereo ARC audio channel transmitting from a connected TV to an audio video receiver or sound bar
  • ARC support for audio being returned from the TV (receiver end) to the transmitter
  • Allows audio break out from a local source
  • Support audio formats- Dolby True HD- DTS-master- etc.
  • Support 3D signals such as Frame Packing- Side-by-Side- Top-to-Bottom- etc.
  • VESA DDC and hot swap technology (HPD)
  • SPDIF output by standard Toslink optical port
  • HDCP 2.0 compatible
  • Slim and compact design
  • Allows cascading to create a larger distribution system
  • Fully compatible with any Evolution by Vanco product
  • Dimensions: 2.7” (68.58mm) W x .7” (17.78mm) H x 3.25” (82.55mm) D

Package Contents:

EVEX2007 (TX & RX)
(2) IR Blasters (TX)
(2) IR Receivers (RX)
(2) DC 5V in line power supply
Product Manual

Additional information

Weight 1.6 lbs
Dimensions 9.1 × 6 × 1.8 in
Type

Technology

1 CAT

Brands

Evolution

Resolution

Full HD 1080p

Transmission Distance

51 – 164 ft
