• Hdmi® Audio Extractor

HDMI® Audio Extractor

SKU: 280573 Categories: ,


  • Use to extract audio signals from an HDMI source
  • Allows simultaneous output of toslink or coaxial digital and stereo 3.5mm analog audio signals
  • Supports 2.0CH/5.1CH audio switch
  • Supports High Definition Resolution 1080p and 3D
  • Supports 225 MHz/2.25 Gbps Per Channel Bandwidth (6.75 Gbps All Channels)
  • Supports 12 Bit per Channel Deep Color- 36 Bit Total
  • Supports Uncompressed Audio LPCM (Linear Pulse Code Modulation)
  • Supports Compressed Audio DTS Digital- Dolby Digital (DTS-HD and Dolby True HD)
  • HDCP Compliant
  • Power Supply: 5V DC- UL Listed
  • Dimensions: 2.75″ W x .75″ H x 2.378″

Additional information

Weight 0.78 lbs
Dimensions 6.62 × 4.5 × 2.5 in
Source Type




280573 Product Manual
