Description
The PulseAudio PA-EXMIX Microphone Mixing Extender over single Cat5e/6 extends analog audio and microphone signals up to 300m/984ft. Mixing is done with an easy-to-use dial on the transmitting unit that is able to mix audio between the XLR and stereo AUX inputs. The PA-EXMIX also utilizes PoC (power over cable) technology so that the transmitter can be powered from the receiver with a single power supply allowing flexibility. Have more than 2 sources needing to be mixed? No problem as an additional PA-TXMIX (sold separately) can be used and cascaded over a single Cat5e/6 for even larger solutions.
- Extends balanced XLR and 3.5 mm stereo audio over a single Cat5e/6 up to 300m/984ft
- Features Power over Cable (PoC), allowing the extender set to be powered with a single power supply, powered on the receiver end
- Mixing built in with an easy to use dial to mix between the XLR and stereo AUX inputs
- Mic input (XLR) and AUX input with balanced level control
- Supports two types of microphones, Dynamic and Condenser
- 12V Phantom power option
- Ability to cascade with connections for additional PA-TXMIX transmitters (sold separately) to add additional sources
- Dimensions: TX: 5” x 2.9” x 1.6” (126mm x 73mm x 41mm); RX: 3.4” x 2.9” x 1.6” (86mm x 73mm x 41mm)
What’s included:
(1) Microphone extender set
(1) 12V power supply
(1) Set of mounting screws
(1) Product manual
